Spesifikasi Sesuai Juknis No. 652/PER/B3/2010
NO NAMA BARANG SPESIFIKASI SAT HARGA
1 PUBLIC ADRESS Features : 1 12.000.000
Build-in 2 rechargeable batteries design. Suitable for both indoor and outdoor using includes broadcastingand singing
The overall sound signal connected to unlimited slave unit to large audience
Top hat design to stand this divice
Echo design suitable teaching, singing and karaoke. Voice priority funcion.
With 3 wired MIC input jacks and 2 wireless microphone, suitable for many people using simultaneously
Rechargeable battery can be easily exchange for replacement
With CD/DVD player/MP3 player/and audio video player on/off switch to save power
New type plactic enclosure, multi-function configuration, built-in LCD or external LCD is selectable, will bring you more perfect audio quality and infinite enjoyment
Specifikation
• Output Power : 200W/4Ω Max, RMS 100W/4Ω
• Speaker : 1PC Treble speaker, 1PC 10" Speaker (100W)
• Rechargeable battery : 12V-7AH2PCS
• Distortion : 1% (at 10W)
• AF Frequency respon : 50Hz-18KHz ±3 dB
• Input Signal : Wired MIC, wireless MIC,AUXIN
• Output Signal : Line Out, Video Out
• Recharge Time : 10-12 Hours
• Working Time : 3-4 Hours
Wireless reiever
• Modulation Mode : FM
• Frequency Range : UHF 400-900MHz
• Frequency Stability : ± 0.0005%
• Sencitivity : ¬95dB S/N > 40dB
• Adjacent Channel Rejection : >80dB
• Image and Spurious Rejection : >80dB
• AF Output : 450mV±50mV
• SNR : >85dB
• Distortion : < 1 %
• Power Source : 12V
• Current Consumption : 130mA±20mA
Wireless Transmitter
• Modulation Mode : FM
• Oscillation Mode : PLL Synthesized
• Channel Number : 1CH/16CH
• Frequency Range : UHF PLL 400-900MHz
• Frequency Stability : ±0.0005%
• Modulation Factor : 25K (±3K)
• Transmitting Power : 10dBm ±0.5dB
• Spurious Emission : >40dB
• Frequency Respon : 80Hx-18KHz(±3dB)
• SNR : >85dB
• Distortion : < 1 %
• Power Source : 3V & 9V
• Current Consumption : 150mA±20mA&50mA±10mA
